MTK-1610 NF4 CAPACITOR SPOT WELDING MACHINE

The machine is intended for capacitor spot welding of parts from non-ferrous metals and alloys (copper and copper alloys, aluminium and aluminium alloys, nickel and nickel alloys), as well as from low-carbon and corrosion-resistant alloys.

The machine allows for welding of parts from reactive and refractory metals and is capable to weld parts with up to 10 times thickness variation.

The benefits and advantages of spot micro welding machines:

ability to weld parts with thickness from 0.1 mm;

ability to weld small-sized parts;

mild pressure is applied to the welded part, despite of the quick movement of an electrode;

durable welded joint free of splashes, faulty fusions and burnt spots;

short period of welding.







         *Please pay attention that the technical specification and the appearance of the equipment placed on this web-site are only for informational purpose and are not a public offer. The producer reserves the right to make any changes.

         **Copying the data without permission of the web-site administration is prohibited.

Supply voltage, V 220

Rated welding current, kA

16

Rated heating current, kA

8

Rated input power, kVA

0,8

Max. storage power, J

600

Movable electrode travel, mm

15

Electrodes outreach, mm

150

Condensers capacity, µF

1200

Electrodes pressing force, daN

1,0...60

Performance, weld./hr

6000

Welded parts thickness, mm

0,05...0,7

Welded parts diameter, mm

0,2...1,5

Gripping mechanism

электромеханический

Overall dimensions:

length, mm

width, mm

height, mm



832

722

1535

Weight, kg

350
